Technical specifications技術(shù)規(guī)格：

Input輸入:

AC Socket:交流輸入接口：  C14 品字尾

Input range交流電壓輸入范圍：90Vac~264Vac

Frequency頻率：47Hz~63Hz

Input current輸入電流：3.2A Max at 90Vac input voltagefficiency：89% Min. at nominal input voltage, maximum load and measured at the end of DC cable

Output輸出

Output Power輸出功率：230W

Output Volts/Amps輸出電壓/電流：19.50V/11.8A

Output ripple and noise輸出紋波：350 mV peak to peak

DC Plug輸出接口: follow up customer request to offer   按照客戶項(xiàng)目需求提供

Dimensions 尺寸(mm)

L165.0 x W76.1 x H31.5
